A fighter-interceptor version of the A-12 reconnaissance aircraft
The YF-12 “Blackbird” was an experimental fighter-interceptor version of the Lockheed A-12 reconnaissance aircraft. In Air Force flight tests on May 1, 1965, the YF-12 set a speed record of 2,070.101 mph and an altitude record of 80,257.65 feet. First publicly displayed at Edwards Air Force Base in 1964, the YF-12 was never adopted by the military as an operational aircraft. It was, however, a precursor to the SR-71 Blackbird reconnaissance plane.
Work on the YF-12 began in secret in the late 1950s at the Lockheed Advanced Development Projects office, better as known the “Skunk Works,” in Burbank, Calif. Flight data remained classified long after President Lyndon Johnson announced the plane’s existence on Feb. 29, 1964. After the announcement, the plane received the Air Force designation YF-12A.
Though the aircraft performed well, the F-12 interceptor program ended in early 1968. High costs, the ongoing war in Southeast Asia, and a lower priority on air defense of the US all contributed to the cancellation.
NASA YF-12C
Taken in 1975, the interesting photos in this post show NASA Blackbirds carrying the so called “coldwall” heat transfer pod on a pylon beneath the forward fuselage.
NASA not allowed to have SR-71s
Taken in 1975, the interesting photos in this post show NASA Blackbirds carrying the so called “coldwall” heat transfer pod on a pylon beneath the forward fuselage.
The Blackbirds portrayed in these photos are usually referred to as YF-12s, but actually one of them was an SR-71: the one on the top is a YF-12 but the one on the bottom is an SR-71.
Another interesting thing about those pictures is that NASA was not allowed to have an SR-71 but they did and they passed it off as a YF-12!
In fact, the “YF-12C” was a then-secret SR-71A (serial no. 64-17951, the second production SR-71A) given the NASA tail no. 60-6937. The reason for this bit of subterfuge lay in the fact that NASA, while flying the YF-12A interceptor version of the aircraft, was not allowed to possess the strategic reconnaissance version for some time.
Noteworthy, the SR-71 differed from the YF-12A in that the YF-12A had a round nose while the SR-71 had its chine carried forward to the nose of the airplane. There were other differences in internal and external configuration, but the two aircraft shared common inlet designs, structural concepts, and subsystems.
The bogus tail number actually belonged to a Lockheed A-12 (serial no. 60-6937), but the existence of the A-12 remained classified until 1982. The tail number 06937 was selected because it followed in the sequence of tail numbers assigned to the three existing YF-12A aircraft: 06934, 06935, and 06936. Isn’t that amazing?
Coldwall project
The coldwall project, supported by Langley Research Center, consisted of a stainless steel tube equipped with thermocouples and pressure-sensors. A special insulating coating covered the tube, which was chilled with liquid nitrogen. At Mach 3, the insulation could be pyrotechnically blown away from the tube, instantly exposing it to the thermal environment. The experiment caused many inflight difficulties, such as engine unstarts, but eventually researchers got a successful flight.
Noteworthy the Flight Research Center’s involvement with the YF-12A, an interceptor version of the Lockheed A-12, began in 1967. Ames Research Center was interested in using wind tunnel data that had been generated at Ames under extreme secrecy. Also, the Office of Advanced Research and Technology (OART) saw the YF-12A as a means to advance high-speed technology, which would help in designing the Supersonic Transport (SST).
Given that the US Air Force (USAF) needed technical assistance to get the latest reconnaissance version of the A-12 family, the SR-71A, fully operational, the service offered NASA the use of two YF-12A aircraft, 60-6935 and 60-6936.
Eventually, with 146 flights between Dec. 11 1969 and Nov. 7 1979, 935 became the workhorse of the program while the second YF-12A, 936, made 62 flights. Given that this aircraft was lost in a non-fatal crash on Jun. 24 1971, it was replaced by the so-called YF-12C SR-71A 61-7951, modified with YF-12A inlets and engines and a bogus tail number 06937.
